Thickness 5.0mm - CSB® Plastic Bearing Technology

Move the table left and right to see more information

Product Type	Part No.	Operation Temperature [oc]	Max. Dynamic Load [MPa]	Max. Static Load [MPa]	Compressive Strength [MPa]	Max.PV [N/mm2xm/s]
Thickness 5.0mm	CRH-100110-100	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-100110-110	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-100110-120	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-100110-80	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-100110-90	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-110120-100	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-110120-110	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-110120-120	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-110120-80	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-110120-90	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-120130-100	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-120130-110	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-120130-120	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-120130-130	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-120130-140	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-120130-150	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-130140-100	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-130140-110	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-130140-120	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-130140-130	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-130140-140	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-130140-150	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-140150-100	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-140150-110	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-140150-120	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-140150-130	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-140150-140	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-140150-150	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-140150-160	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-140150-170	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-140150-180	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-150160-100	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-150160-110	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-150160-120	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-150160-130	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-150160-140	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-150160-150	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-150160-160	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-150160-170	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-150160-180	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-2030-15	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-2030-20	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-2030-25	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-2030-30	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-2232-15	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-2232-20	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-2232-25	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-2232-30	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-2535-20	-196/+200	160	420	620	1.5
Thickness 5.0mm	CRH-2535-25	-196/+200	160	420	620	1.5
